mcr GWD-1 i mcr GWD-2 WIND-RAIN SENSOR
The device consists of two components:
WM wind sensor:
- sensor for measuring wind speed
- sold with rain sensor on mounting console
RS rain sensor:
- heated rain sensor (heating is enabled after
sensor fuseing and is disabled after its drying) - gold-plated sensing area 80 cm2
- sold with wind sensor on mounting console
- The GWD-1 wind and rain sensor is used together with the weather control unit in natural ventilation systems to automatically close vents/windows in the event of rain or wind.
- The GWD-2 wind and rain sensor is used in natural ventilation systems to automatically close vents/windows in the event of rain or wind. The D potentiometer allows adjustment of the rain sensor sensitivity from light rain (turn left) to heavy rain (turn right). The W potentiometer allows adjustment of the wind sensor sensitivity from 5 m/s (turn right) to 15 m/s (turn left).
- The sensor is equipped with a potential-free changeover contact with a maximum switching capacity of 1 A.
Information
Weather control unit mcr P054
mcr SVM
mcr SV-ds
mcr 9705
mcr 0204 | PARAMETER | VALUE | ||
|---|---|---|---|
| GWD-1 | GWD-2 | ||
| compatible control units | mcr P054 | mcr SVM, mcr SV-ds, mcr 9705, mcr 0204 | |
| enclosure protection rating | IP 54 | ||
| cable cross-section range | 0.35 ÷ 1.0 mm2 | ||
| dimensions (height x width x depth) | 80 x 120 x 40 mm | ||
| required number of cable cores | 3 | 4 | |
| color | RAL 7035 (light grey) | ||
