mcr PROLIGHT CONTINUOUS ROOFLIGHTS

DESCRIPTION

continuous rooflights with span up to 6.0 m
bottom part of base has a circumferential flange of standard width 70 mm,
for installing on the roof structure
skylight base stiffened with bracing at 1500 mm or 3000 mm
products are delivered to construction site in elements and assemble in two steps:
– first step - base
– second step - top section
RAL palette colour selection for elements
CE marked rooflights according to EN 14963
fire performance for external fire, class B_ROOF(t1) in accordance with PN-EN 13501-5+A1

DESIGN
Base

type: straight, ridge, slope, overlay, broken at the ridge
height: 30 cm - 70 cm
material: PVC, steel, aluminum
prepared insulation of 50 mm thickness (possible modification)
possible to apply on existing plinth

Filling

multi-chamber polycarbonate
multivariable single and multi-layer filling

Ask for an offer

Other continuous rooflight structures (custom solutions)

TRIANGULAR SHAPED ROOFLIGHTS

PYRAMID SKYLIGHT

DOME SKYLIGHT

Lighting

Effective method of increasing natural light intensity in rooms and contribute to reducing total cost of energy.

Heat transfer

Product allows to achieve high heat transfer:

Urc ≥ 0,95 W/m²K.

Additional elements

» wind deflectors
» inlet deflectors
» safety net
» limit switch

Ask for an offer
