mcr AR/AWR - WIND & RAIN SENSOR
The wind and rain sensor consists of a wind force sensor and a rain sensor. It is designed to control the operation of vent actuators or ventilation windows, which should be closed in case of rain or wind. The sensor is equipped with a potential-free relay with a load capacity of 250 V~ / 8 A or 24 V- / 8 A. In the event of wind and/or rain, the relay is activated. The wind action point settings are adjusted by a rotary switch on the main board. It is designed for mcr SVM or mcr SV-ds control units.
The mcr AR/ARW sensor cooperates with the mcr SVM and mcr SV-ds control units.
| mcr SVM | mcr SV-ds |
|
|
|
| more | more |
Information
| Technical Data | |
|---|---|
| Power supply: |
18 V - 35 V / 2 0V - 35 V- / 200 V - 250 V~ |
| Output contact: |
NO-NC 1 x potential free change-over contact |
| Contact rating: |
250 V~ / 8A lub 24 V- / 8 A |
| Dimensions: |
80 x 160 x 55 mm (W x H x D / without wind wheel) |
| Weight: |
Approx. 0,7 kg |
| Protection class: |
IP65 |
| Setting of the wind mode: |
ok. 1 - 9 m/s (+-20%) |
| CE-marking: |
in accordance with the EMC – directive and low voltage directive |
| The sensor must be cleaned regularly, depending on soil degree, with a wet cloth with water - non abrasive | |
