mcr ULTRA THERM SMOKE VENTS

DESCRIPTION

  • high thermal insulation
  • no thermal bridges
  • various shapes and base materials
  • wide scope of vents sizes:
  • –  Type C (square): 100 x 100 cm ÷ 200 x 200 cm
    –  Type E (rectangular): 80 x 120 cm ÷ 200 x 250 cm
    –  Type NG-A (skew base): 80 x 120 ÷ 200 x 300 cm
  • optional wind – and/or inlet deflector for better aerodynamic performance
  • partial or complete product delivery
  • RAL palette colour selection for steel and aluminum bases
  • aesthetic design
  • product certified according to PN EN 12101-2, CE marked


DESIGN
Base

  • type: straight, skew
  • height: standard   30 cm - 50 cm; 25 cm - 70 cm  (additional option)
  • material: PVC, steel, aluminium
  • steel or aluminum base prepared for insulation of 50 mm thickness
  • possible to instal on existing plinth

Filling

  • multi-chamber polycarbonate
  • domes: acrylic or solid polycarbonate
  • ALU sandwich panel
  • multivariable single and multi-layer filling

Control system

  • smoke exhaust: pneumatic, electric (24 V- / 48 V-)
  • ventilation: electric (230 V~)
Ask for an offer

Information

 Smoke exhaust



Exhaust smoke, combustion gases and heat energy from enclosed spaces (production floors, storage spaces, public facilities, etc.) to the outside of builings, in order to protect human lives and property.
 Lighting



Effective method of increasing natural light intensity in rooms and contribute to reducing total cost of energy.
 Ventilation



Provides air supply and daily ventilation.
 Additional elements



» wind deflectors
» inlet deflectors
» safety net
» limit switc
 Heat transfer


Product allows to achieve high heat transfer:

Urc ≥ 0,8 W/m²K.
 Application



Wide scope of shapes and sizes enable
installation on warehouses, public
services buildings, shopping malls,
commercial and sport objects.
