mcr ULTRA THERM SMOKE VENTS WITH ROOF ACCESS FUNCTION
DESCRIPTION
- high thermal insulation
- no thermal bridges
- various shapes and base materials
- wide scope of vents sizes:
– Type C (square): 100 x 100 cm ÷ 115 x 115 cm*
– Type E (rectangular): 80 x 120 cm ÷ 200 x 250 cm*
– Type NG-A (skew base): 90 x 120 cm ÷ 200 x 250 cm* - partial or complete product delivery
- RAL palette colour selection for steel and aluminum bases
- aesthetic design
- product certified according to PN EN 12101-2, CE marked
(*) The selection of vents with a hatch function should
be consulted with the sales department*
DESIGN
Base
- type: straight, skew
- height: standard 30cm (skew), 30 cm - 50 cm (straight);
25 cm - 70 cm (additional option) - material: PVC, steel, aluminium
- steel or aluminum base prepared for insulation of 50 mm thickness
- possible to instal on existing plinth
Filling
- multi-chamber polycarbonate
- domes: acrylic or solid polycarbonate
- ALU sandwich panel
- multivariable single and multi-layer filling
Control system
- smoke exhaust: pneumatic, electric (24 V- / 48 V-)
- ventilation: electric (230 V~)
Information
|
|
|
|
|
|
Smoke exhaust
Lighting
Ventilation
Additional elements
Heat transfer
Roof access
