ELECTRIC ACTUATORS 230 V~ FOR VENTILATION
Actuators for ventilation are used for smoke ehaust vents with pneumatic control and vents in continuous rooflights.
Types of 230 V~ electric actuators:
Electric actuators: Type E
They can be controlled by a ventilation button LT
and/or by the mcr P054 weather monitoring unit.
| LT | mcr P054 |
|
|
|
| more | more |
Information
» Dane techniczne siłownika elektrycznego E
| ACTUATOR TYPE | LOAD CAPACITY [N] |
CLOSING FORCE [N] |
POWER CONSUMPTION [W] |
EXTENSION [mm] |
CASING MATERIAL | OPERATING MODE (AS PER DIN VDE 0530) |
|---|---|---|---|---|---|---|
| E-300-230 | 500 | 250 | 23 | 300 | plastic | S3 25% |
| E-500-230 | 500 | 250 | 23 | 500 | plastic | S3 25% |
| E-750-230 | 500 | 250 | 23 | 750 | plastic | S3 25% |
» Dimensions of selected ventilation boxes
| BOX TYPE | BOX DIMENSIONS width x height x depth [mm] |
Notes |
|---|---|---|
| PLZ 10.0.1 | 300 x 200 x 80 | for single ventilation group, manual control |
| PLZ 20.1.1-EA230-EZ230 | 300 x 200 x 80 | 1 smoke exhaust group – opening only (co-operation with alarm box for opening), 1 ventilation group – with possible ventilation control through 230 V~ signal. |
| PLZ 30.1.1-EZ-230-EA230 | 300 x 200 x 80 |
1 smoke exhaust group – opening and closing (co-operation with alarm box for opening and closing),
|
