VENTILATION BOXES
Ventilation boxes are used for remote control of the actuators that open and close the ventilation vents. The boxes contain valves that control the opening and closing of the vents leaf and the air preparation system.
Specific features:
- steel box painted in RAL 5012 color
- lockable door, opened to the bottom in standard
- valves control through levers outside the box
- Ø6 mm pipe connections
- includes filter, dehydrator, pressure reducer (output pressure 0÷1 MPa)
- Possible configurations:
options 1: valves control lever located inside, no air preparation system,
options 2: co-operation with alarm box, weather monitoring unit,
electric or pneumatic remote opening and closing.
Information
| BOX TYPE | BOX DIMENSIONS width x height x depth [mm] |
Notes | |
|---|---|---|---|
| PLZ 10.0.1 | 300 x 200 x 80 | for single ventilation group, manual control | |
| PLZ 20.1.1-EA230-EZ230 | 300 x 200 x 80 | 1 smoke exhaust group – opening only (co-operation with alarm box for opening), 1 ventilation group with possible ventilation control through 230 V~ signal |
|
| PLZ 30.1.1-EZ-230-EA230 | 300 x 200 x 80 | smoke exhaust group – opening and closing (co-operation with alarm box for opening and closing), 1 ventilation group with possible ventilation control through 230 V~ signal |
|
