mcr WIP PRO/V - MULTI-BLADE SMOKE EXHAUST FIRE DAMPER

mcr WIP PRO/V cut-off dampers are designed for installation in automatically-activated fire ventilation systems. They support single fire zones, as well as several zones within a single facility. They prevent propagation of fire, smoke and fire gases to the neighbouring zones. The dampers can operate in so-called mixed systems (/V-M variant).

Cut-off dampers for multi-zone fire ventilation systems, of resistance independent from direction of air flow and from installation side.

Fixed, narrow damper thickness, regardless of BxH dimensions.

FEATURES

• small thickness of damper - 135 mm
• cut-off barrier does not protrude outside the damper body, regardless of damper dimensions
• possible installation in a partition, on a duct ended with a duct cover
• optional making of dampers with penetrations for rounded ducts
• operating reliability up to 10 000 cycles

APPLICATION

• PRODUCTION HALLS AND WAREHOUSES
• LOGISTICS CENTERS
• PUBLIC BUILDINGS
• COMMERCIAL BUILDINGS
• RESIDENTIAL BUILDINGS

ADDITIONAL DESCRIPTION

Making variants:

mcr WIP PRO/V [BE, BLE] – cut-off fire damper for multi-zone fire ventilation systems with actuator - damper shutting and opening using actuator
