mcr ULTRA THERM ROOF HATCH

DESCRIPTION

high thermal insulation
mnimal amount of thermal bridges
wide scope of hatches sizes:
– Type C (square): 80 x 80 cm ÷ 130 x 130 cm
– Type E (rectangular): 80 x 90 cm ÷ 120 x 130 cm
– Type NG-A (skew base): 90 x 90 cm ÷ 140 x 140 cm
partial or complete product delivery
RAL palette colour selection for stee and aluminum bases
product certified according to PN-EN 1873

More

DESIGN
Base

type: straight, skew
height: standard 30 - 70 cm, 25 - 70cm (additional option)
material: PVC, steel, aluminum
steel or aluminum base prepared for insulation of 50 mm thickness

Filling

multi-chamber polycarbonate
domes: acrylic or solid polycarbonate
multivariable single and multi-layer filling

Control system

gas springs

Ask for an offer

Lighting

Effective method of increasing natural light intensity in rooms and contribute to reducing total cost of energy.

Heat transfer

Product allows to achieve high heat transfer:

Urc ≥ 0,8 W/m²K.

Roof access

Opening mechanism enables easy roof access.

Additional elements

» safety net

Application

Wide scope of shapes and sizes enable
installation on warehouses, public
services buildings, shopping malls,
commercial and sport objects.

Technical Catalogue

OMM

Ask for an offer
