mcr ULTRA THERM - FIXED SKYLIGHTS
DESCRIPTION
- high thermal insulation
- no thermal bridges
- wide scope of skylight sizes:
– Type C (square): 80 x 80 cm ÷ 200 x 200 cm
– Type E (rectangular): 80 x 120 cm ÷ 200 x 300 cm
– Type NG-A (skew base) 80 x 80 cm ÷ 200 x 300 cm - partial or complete product delivery
- leaf frame made of white, multi-chamber PVC profile system provides rigidity,
strength and high thermal parameters. - RAL palette colour selection for steel and aluminum bases
- resistance to external fire, BROOF(t1) class according to EN 13501-5 (optional)
- skylight available in configuration with soft body impact resistance
up to 1200 J (SB 1200) - product certified according to PN-EN 1873
DESIGN
Base
- type: straight, skew
- height: 30 cm - 50 cm (straight), 25 cm - 70 cm (C/E)
30 - 70cm (NG-A) (additional option) - material: PVC, steel, aluminum
- steel or aluminum base prepared for insulation of 50 mm thickness
- possible to apply on existing plinth
Filling
- multi-chamber polycarbonate
- domes: acrylic or solid polycarbonate
- multivariable single and multi-layer filling
Information
|
|
|
Lighting
Heat transfer
Additional elements
