mcr ULTRA THERM FIX - FIXED SKYLIGHTS

DESCRIPTION

  • high thermal insulation
  • no thermal bridges
  • various shapes and base materials
  • wide scope of skylight sizes:
    –  Type C (square): 80 x 80 cm ÷ 190 x 190 cm
    –  Type E (rectangular): 80 x 120 cm ÷ 200 x 300 cm
    –  Type NG-A (skew base) 80 x 80 cm ÷ 200 x 300 cm
  • partial or complete product delivery
  • RAL palette colour selection for steel and aluminum bases
  • resistance to external fire, BROOF(t1) class according to EN 13501-5 (optional)
  • skylight available in configuration with soft body impact resistance
    up to 1200 J (SB 1200)

DESIGN
Base

  • type: straight, skew
  • height: 30 cm – 70 cm (straight), 25 cm - 70 cm (C/E)
    30 - 70cm (NG-A) (additional option)
  • material: PVC, steel, aluminum
  • steel or aluminum base prepared for insulation of 50 mm thickness
  • possible to apply on existing plinth

Filling

  • multi-chamber polycarbonate
  • domes: acrylic or solid polycarbonate
  • multivariable single and multi-layer filling

Ask for an offer

Information

 Lighting



Effective method of increasing natural light intensity in rooms and contribute to reducing total cost of energy.
 Heat transfer


Product allows to achieve high heat transfer:

Urc ≥ 0,8 W/m²K.
 Additional elements



» safety net
» limit switch

Ask for an offer
