mcr PROSMOKE AUTOMATIC SMOKE CURTAINS

DESCRIPTION

  • automatic smoke curtains FS and CE are responsible for separation of smoke zones within the building, and stop smoke from spreading within passages, on staircases or escalators
  • automatic smoke curtains are used in buildings where the visual aspect of building plays an important role
  • fire resistance parameters:
    –  automatic curtains FS: D30 / DH60 lub D180
    –  automatic curtains CE: D30 / DH60 / DH30 / DH60
  • vast range of curtain mounting to ceiling lintel or object steel construction
  • automatic curtain as one folded or modular device can be connected under an angle or contain evacuation entrance
  • painting steel components with chosen RAL palette colour
  • classification (as per EN 12101) according to:
    –      Certificate of constancy of performance 1396-CPR-0033
        (mcr PROSMOKE FS curtains)
    –  Certificate of constancy of performance 1396-CPR-0021
        (mcr PROSMOKE CE curtains)

DESIGN
Base

  • mcr PROSMOKE CE – automatic smoke curtain
    (rolled and unrolled with motor)
  • mcr PROSMOKE FS – automatic smoke curtain
    (fail-safe gravitational drop)

Automatic curtain - structure

  • steel sheet casing with roller
  • incombustible fabric
  • motor
  • bottom balast
  • masking element




Ask for an offer

Information

  Separation of smoke zones



Separated smoke zones stop the spread of smoke in passageways, staircases, stairs and hold the smoke in a room adjacent to the evacuation route. Correct arrangement of smoke curtains in the facility allows the smoke to be directed towards other system devices - smoke vents.
 Smoke flow optimisation
       and gas redirection into smoke vents



Proper placement of smoke curtains in a building makes it possible
to direct the smoke towards other elements of the system, i.e. smoke vents.
 Non-standard options



» elements painted to any RAL colour
» service passage
» guides
 Application



Wide scope of shapes and sizes enable installation on warehouses,
public services buildings, shopping malls, commercial and sport objects.
