mcr PROLIGHT VENTILATION VENTS

DESCRIPTION

  • wide scope of vents sizes:
    –  Type C (square): 80 x 80 cm ÷ 200 x 200 cm
    –  Type E (rectangular): 100 x 120 cm ÷ 195 x 250 cm
    –  Type NG-A (skew base) 100 x 100 cm ÷ 200 x 300 cm
  • vents are delivered to site construction as a complete product, ready to install
  • RAL palette colour selection for vent elements
  • product certified according to PN-EN 1873+A1


DESIGN
Base

  • type: straight, skew
  • height: standard 30 cm - 50 cm (straight); 25 cm - 70 cm (additional option)
  • material: PVC, steel, aluminium
  • thermal insulation with mineral wool or PIR panel
  • possible to apply on existing plinth

Filling

  • multi-chamber polycarbonate
  • domes: acrylic or solid polycarbonate
  • ALU sandwich panel
  • multivariable single and multi-layer filling

Control system

  • smoke exhaust: pneumatic, electric (24 V- / 48 V-)
  • ventilation: electric (230 V~)

Ask for an offer

Information

 Lighting



Effective method of increasing natural light intensity in rooms and contribute to reducing total cost of energy.
 Heat transfer


Product allows to achieve high heat transfer:

Urc ≥ 1,41 W/m²K.
 Ventilation



Provides air supply and daily ventilation.
