mcr MONSUN T-CL Axial Smoke Extraction Fan



Ask for an offer

Information

The mcr MONSUN T-CL axial smoke extraction fan is designed for single or two-speed operation for conveying and extracting hot smoke and heat in buildings. The device protects the building structure and prevents fire from spreading to unaffected rooms. The fan is intended for emergency smoke extraction, with the motor located in the hazard zone. The housing is equipped with inspection doors for motor access and has a polyester powder-coated finish.

Additional information:



  • Operation inside and outside the smoke reservoir
  • Reinforced round housing
  • Fan available in EX (ATEX) version
  • Dimensions: D400 - D1600 [mm]
  • Protection rating: IP 55
  • Nominal power: 0.55 kW – 75 kW
  • Rotational speed: 750; 1000; 1500; 3000 rpm
  • Operating mode: unidirectional, reversible
  • Execution type: single-speed, two-speed
