mcr MONSUN T-CCT Axial Smoke Extraction Fan

Fire resistance class: F400 – 400°C / 120 min

Fan classified according to EN 13501-4

Performance properties in accordance with EN 12101-3

CSWU: 0370-CPR-7523



Ask for an offer

Information

The mcr MONSUN T-CCT axial smoke extraction fan is designed for single or two-speed operation for conveying and extracting hot smoke and heat in buildings. The fan features a sound-absorbing galvanized steel casing with special removable insulation panels for easy access to the motor and convenient maintenance. The housing has an epoxy powder-coated finish.

Additional information:

  • Operation inside and outside the smoke reservoir
  • Box-type housing, thermally and acoustically insulated
  • Fan available in EX (ATEX) version

Technical data:

  • Dimensions: D400 - D1250 [mm]
  • Protection rating: IP 55
  • Nominal power: 0.55 kW – 37 kW
  • Rotational speed: 750; 1000; 1500; 3000 rpm
  • Operating mode: unidirectional, reversible
  • Execution type: single-speed, two-speed
