mcr MONSUN R - AXIAL SMOKE EXHAUST REVERSIBLE FAN / SMOKE EXHAUST EXPLOSION-PROOF FAN

Key details

Fire resistance classes:

  • class F300 – fire resistance 300°C/60 min.  certified for conformance with EN13501-4:2016
  • class F400 – fire resistance 400°C/120 min. certified for conformance with EN13501-4:2016

Additional details

Certificate of constancy of performance 0370-CPR-1843 for F400.
Certificate of constancy of performance 0370-CPR-1844 for F300.
Declaration of performance 003-00-CPR-2014.
Declaration of performance 004-00-CPR-2014.

Ask for an offer

Information

mcr Monsun R axial fans are used in fire ventilation systems for smoke exhaust and air supply, where reversibility of the system or explosion-proof making is required.

Smoke fans are used for removing heat, smoke and combustion gases generated in rooms during fire. They facilitate evacuation of people from fire zone, as well as fire fighting operations carried out by fire brigades. They also protect the building structure and its equipment from the effect of high temperature, and prevent spreading of fire to adjacent areas.

The devices are adapted for outdoor, as well as indoor operation.

FEATURES

  • possibility of reversible work
  • possibility of vertical and horizontal installation
  • possibility of making in ATEX explosion-proof variant

APPLICATION

  • PRODUCTION HALLS AND WAREHOUSES
  • LOGISTICS CENTERS
  • PUBLIC BUILDINGS
  • COMMERCIAL BUILDINGS
  • RESIDENTIAL BUILDINGS

ADDITIONAL DESCRIPTION

Making variants:

  • one-speed
  • two-speed
  • reversible
  • ATEX explosion-proof

Accessories:

  • SW-c mounting feet
  • KD-c flexible connections
  • PK-c counter flanges
  • TH-c noise silencers
  • WS service switches
  • AM/BM shock absorbers
  • SO-c cover grills
  • available diameters: 400, 450, 500, 560, 630, 710, 800, 900, 1000, 1250, 1400, 1600 mm
  • efficiency up to 130 000 m3/h
  • max. compression up to 1 250 Pa
  • nominal power 0.55 kW - 55 kW
  • rotation speeds n = 750; 1 000; 1 500; 3 000 RPM
  • IP 55 protection class

Detailed technical specifications are contained in the technical catalogue.
