FLOW REGULATOR WITH THERMAL SWITCH (THERMAL TRIPPER)
Thermal release valve is used for supplying pneumatic pressure to smoke exhaust actuator from its integrated CO2 cartridge or CO2 installation. The released gas is directed to pneumatic smoke exhaust actuator, causing the opening of the vent leaf.
Specific features of thermal valves:
- options:
– TAVE/TAG-WV 690-41 - opening only
– TAVZ/TAG-WV 690-42 - opening and closing - disposable CO2 cartridge with 1/2” UN threaded connection
- alcohol ampules for temperatures: 68°C, 93°C, 110°C, 141°C, 182°C
- maximum working pressure: 6 MPa
- for needle tensioning and ampule replacement in TAVE/TAG-WV 690-41
or TAVZ/TAG-WV 690-42 thermal valves no tools are required.
Information
TAVE/TAG-WV 690-41 type
- smoke exhaust function: manual and remote vent opening (opening only),
- a thermal release adapted to work with an alarm box equipped only with the function of manual alarm opening,
- may be used for single and triple pipe installations,
- 2 x 1/8” connectors,
- integrated initial valve for deaeration of the system or for connecting other
- control devices (e.g. alarm box or ventilation box),
- optional remote activation through electric signal or pneumatic pressure, which enables cooperation with other control systems, e.g. SSP.
TAVZ/TAG-WV 690-42 type
- smoke exhaust function: manual and remote vent opening and closing
- a thermal release adapted to work with an alarm box equipped with the function
of manual alarm opening and closing, - May be used for double and four-pipe installations,
- 4 x 1/8” connections,
- ntegrated initial valve for ventilation of the system or for connecting other control devices (e.g. alarm box or ventilation box),
- optional remote activation through electric signal or pneumatic pressure pressure, which enables cooperation with other control systems, e.g. SSP.
