ELECTRIC ACTUATORS - SMOKE EXHAUST AND VENTILATION

Type of electric actuators:

Spindle electric actuators: Type S / Type G
Chain electric actuators: HCV / HCVA / HCV Door Drive

G and S type electric actuators are used to open the smoke exhaust vents and windows,
as well as for daytime ventilation, while the HCV/HCVA type actuators are used to open smoke exhaust windows and in the case of HCV Door Drive, to open the ventilation doors. They are powered by 24 V-, 48 V- or 230 V~ voltage.

They are equipped with a suppression capacitor, overload switch and limit switches
as standard. IP 40 degree of protection for G type actuators (available options: IP 42
for S actuators, IP 20 for HCV/HCVA/HCV Door Drive actuators).

Ask for an offer

» Type S spindle electric actuators

ACTUATOR TYPE	SUPPLY VOLTAGE [V]	NOMINAL POWER CONSUMPTION [A]	ACTUATOR STROKE [mm]	DIMENSIONS (LxBxH) [mm]	MAXIMUM OPERATING TEMPERATURE [ºC]
S08B-200	24	0,8	200	452 x 36	-25 ÷ +60
S08B-300	24	0,8	300	552 x 36	-25 ÷ +60
S10C-350	24	1,0	350	602 x 36	-25 ÷ +60
S10C-400	24	1,0	400	652 x 36	-25 ÷ +60
S10C-450	24	1,0	450	702 x 36	-25 ÷ +60

» Type G spindle electric actuators

ACTUATOR TYPE	SUPPLY VOLTAGE [V]	NOMINAL POWER CONSUMPTION [A]	ACTUATOR STROKE [mm]	DIMENSIONS (LxBxH) [mm]	MAXIMUM OPERATING TEMPERATURE [ºC]
G26G/H-550	24	2,6	550	839 x 58 x 47	-25 ÷+60
G26G/H-600	24	2,6	600	889 x 58 x 47	-25 ÷+60
G26G/H-750	24	2,6	750	1039 x 58 x 47	-25 ÷+60
G40H-830	24	4,0	830	1119 x 58 x 47	-25 ÷+60

» HCV electric chain actuator (24 V- / 48 V-)

ACTUATOR TYPE	SUPPLY VOLTAGE [V]	NOMINAL POWER CONSUMPTION [A]	ACTUATOR STROKE [mm]	DIMENSIONS (LxBxH) [mm]	MAXIMUM OPERATING TEMPERATURE [ºC]
HCV 500/350	24 48	1,4 0,7	350	436 x 51 x 40	25 ÷ +75
HCV 500/600	24 48	1,4 0,7	600	561 x 51 x 40	25 ÷ +75
HCV 500/800	24 48	1,4 0,7	800	661 x 51 x 40	25 ÷ +75
HCV 500/1000	24 48	1,4 0,7	1000	766 x 51 x 40	25 ÷ +75

» HCVA electric chain actuators (230 V~)

ACTUATOR TYPE	SUPPLY VOLTAGE [V]	NOMINAL POWER [A]	ACTUATOR STROKE [mm]	DIMENSIONS (LxBxH) [mm]	MAXIMUM OPERATING TEMPERATURE [ºC]
HCVA 500/350	230	30	350	586 x 51 x 40	-5 ÷ +55
HCVA 500/600	230	30	600	711 x 51 x 40	-5 ÷ +55
HCVA 500/800	230	30	800	811 x 51 x 40	-5 ÷ +55
HCVA 500/1000	230	30	1000	916 x 51 x 40	-5 ÷ +55

» Electric chain actuator mcr HCV Door Drive 24/36/48 V- for all doors

Model	Power supply	Pushing / pulling force (N)	Opening angle	Locking pressure	Protection	Temperature	Speed (mm/sec.)	Size (mm) (L x W x H)
HCV 500/600mm	24 V- / 1.4 A 36 V- / 1.05 A 48 V- / 0.7 A	500 / 500	90°	2000 N	IP 32	-25°C - +75°C	10	587 x 82 x 41
